XLPE Insulated Wire 125℃ EV

Product group XLPE Insulated Wire 125℃
Country of origin China
Listed on Jan 21, 2023

Seller information

Visit store
  • 199 Hengxiang Road, Waigang Town, Jiading District, Shanghai, 201806, China
  • +86 13321979392
  • Manufacturer
  • Established 1998
  • 500 employees

Description

Report this item

▪ 28AWG~120mm²,stranded or solid
▪ Bare copper or tin-plated copper wire
▪ Insulation:Extruded XLPO or XLPE
▪ Temperature range:-40~125℃
▪ Rated voltage:600V/1500V

Options:

▪ Shielding (optional): bare copper / tinned copper wire braided + aluminum foil wrapping.
▪ Colour:red / yellow / blue / white / black / yellow green / brown, etc.
(Two-color insulation/ Surface marking)
Characteristics:
▪ RoHS Compliant

XLPE:

▪ Excellent electrical insulation properties.
▪ Halogen-free, good environmental protection.
▪ Good mechanical properties and good wear resistance.
▪ Passed a single vertical combustion test, has good flame retardancy.
▪ Good heat resistance, long-term working temperature can reach 125 ℃.
▪ Excellent low temperature toughness, and has passed the low temperature bending test of -40 ℃.
▪ Strong acid and alkali resistance and oil resistance.
▪ The combustion releases water and CO2, less harm to the environment and conforms to the modern fire safety request.

Application:

The products are widely used in electrical wiring harnesses, sensing lines, PTC thermistors, coating equipment, automotive internal connection lines, motors, lighting fixtures, electronic appliances, voltage cabinets, high-voltage motors, and other fields.

The Production standards comply with ISO 6722; QC/T 1037; LV 216 etc.

LV 216 specifies cable design, dimensions, etc
Customer requirements for the basic properties of silicone rubber: Tensile strength > 8 MPa Elongation > 300% Hardness 55-70 ShA
Class E(180 ° C hybrid) and Class F(200 ° C) require silicone rubber
Class E
Tear Strength ISO 34-1 B > 15 N/mm
Long-term aging of cable 180℃*3000 hours
Class F
Long-term aging of cable 200℃*3000 hours
Tear Strength ISO 34-1 B > 10 N/mm
