Bosa LF230 Battery Cell

Description

Cell Type: LF230
Nominal Capacity(Ah): ≥230
Minimal Capacity(Ah): 230
Nominal Voltage(V): 3.20
Internal Imbedance (mΩ): ≤0.30
Charging Cut-off Voltage (V): 3.65
Discharging Cut-off Voltage (v): 2.5
Standard Charging Current (A): 0.5 C
Standard Discharging Current (A): 0.5 C
Charging Time (H): 3
Charge Method: Standard charge method: 0.5 C, Rapid charge method: 1.0 C
Max Continuous Discharge: 1.0 C
Nominal Energy (Wh): 736
Cycle Life: 25℃ Standard Cycle: ≥3500, 45C Standard Cycle: ≥1800
Max. Pulse(10sec) Discharge: 2.0 C
Operating Temperature Range: Charge(°C): 0°C~60 ℃, Discharge(°C): -30C~60 ℃
Storage Temperature: one month: -20°C~45 ℃, one year: 0°C～35°C
Energy Density: 179.08Wh/kg:
Dimension: Width: 173.93土0.50mm, Thickness(300+20kgf,40%SOc): 53.85土0.40mm, Average thickness(300±20kgf, 40%SOC): 53.85土0.15mm, High(total): 207.30±0.50mm, High(subject): 204.60±0.50mm, Tab Distance: 123.00土0.30mm
Cell Weight (kg): 4.11±0.10kg
