Veritek Multifunction Meter VIPS 69

Description

Veritek Multifunction Meter with LED Display, four rows of four digits for multi-parameter display with communication port.

Features:

• 7-segment bright red LED display Site Programmable CT and PT ratio True RMS measurement
• Password protection
• Optional features (a) 60A direct current (External CT module available)
• Harmonic measurement (Total & Individual) Auto-ranging
• Universal Auxiliary supply
• To caution on the Extra Energy Consumption
• To identify inefficiency of Machine/Man
• Reduce Panel Space, Wiring, Installation Time

Applications:

• Control Panel Distribution System
• The generator sets the Motor Control
• Test Bench
• Energy Management Process Control & SCADA

Specifications :

Display: LED display 3 rows of 4 digits
Digit height: 0.56” (14.3 mm)
Display Scrolling: Automatic/ Manual
Display Reset: Energy
Electrical Connection: 3Φ- 4 wire/ 1Φ- 2 wire
Input Voltage Range: 0-500 VAC (L-L)
Input Current Range: 0.015 A – 6 A AC/ Direct 60 A optional
Frequency: 45 Hz to 65 Hz
Communication: RS 485 Modbus Protocol
Relay Output: 1 C/O relay for max demand
C.T. primary: Programmable
C.T. Secondary: Programmable
P.T Ratio: Programmable
Dimension: 96 x 96mm, Depth ( behind bezzel ) : 55 mm, Panel Cut out : 92 X 92 mm

Additional information:

Weight: 1 kg
Dimensions: 10 × 10 × 10 cm
