UltraFast Femtosecond Laser Cutting Machine For stent(ThreeAxis & Infrared &Green light )

Changzhou MEN-Luck Intelligent Technology Co., Ltd

Description

Super fast femtosecond stand laser cutting machine description

Super fast femtosecond stent laser cutting machine can also be called infrared laser cutting machine or three axis laser cutting machine, mainly used for intracranial thrombectomy, nerve intervention, peripheral, stone basket and other metal and non-metal stent laser microprocessing. The equipment adopts the processing mode of infrared and green femtosecond laser. The finished product has the advantages of smooth incision, no burr edge and minimal heat affected zone. Super fast femtosecond bracket laser cutting machine through CE, ISO9001, ISO13485 3C certification, quality assured!

Equipment parameters

Maximum operating speed 500mm/s（X）；100mm/s（Z）；600rpm（θ）
Positioning accuracy ±1um（X）；±3um（Z）；±15arcsec（θ）
Repetitive positioning accuracy ±0.2um（X）；±1um（Z）；±3arcsec（θ）
Cutting seam width 15um~25um
Consistency of reinforcement width <±5um
Machining material 316L & Ni -Ti & L605 & Fe & Mg & Zn & PLA & PLLA & PI & Nylon & glass, metal & nonmetal materials
Tube blank length <2.5m (customized support fixture)
Laser wavelength 1030-1070±10nm
Processing wall thickness 0~0.5±0.02 mm
Processing tube diameter Φ0.1~Φ7.5±0.02 mm&Φ0.3 ~Φ16.0±0.02 mm&Φ1.0 ~Φ30.0±0.02
Single processing range 0～300mm (longer products will be machined by segmented splicing method);
Laser type Infrared green femtosecond laser
Laser wavelength 1030nm~1070nm±10nm&532nm±10nm
laser power 10W&16W&20W for option
Equipment power supply 220V± 10%, 50Hz；AC 25A (main circuit breaker);
File format DXF、DWG
Equipment dimensions 2100mmx1250mm（1000mm）x1750mm
Equipment weight 1800Kg

Strong adaptability

Have the ability of laser dry cutting & wet cutting & drilling & slotting and other fine machining technology
Support machining of radial opening feature of equal diameter tube
Can machine 304 & 316L & Ni-Ti & L605 etc. materials
Can aachine equal diameter tube & deformed tube & semi-finished tube &small format plane instrument
Adopt the combined precision thin-walled tube shaft sleeve support system with self-adaptive shape tolerance variation
Compatible with precision D-type chuck & ER series chuck & three-jaw chuck and other precision thin-walled tube clamping system
Provide the matching scheme of precision thin-walled tube continuous automatic feed machining & automatic loading and unloading
Equipped with self-developed 2D & 2.5D & 3D CAM software system for laser micromachining

Brand

MenLuck

Model

ML-MDFS300

Country of origin

china

Listed on

Aug 1, 2025

Listing id

927818
