Paper Industry Fans

Paper Industry Fans
Product Overview
Paper Industry Fans are industrial air-handling fans designed for pulp and paper manufacturing, paper machine ventilation, paper drying, hot air circulation, exhaust, dust collection, waste gas treatment, boiler combustion air, flue gas exhaust, and material conveying systems.
EMS supplies a wide range of industrial centrifugal fans, heavy-duty process fans, high-temperature fans, dust extraction fans, boiler fans, and corrosion-resistant fans for paper mills. Fan construction, materials, impeller design, sealing, bearings, and drive systems can be customized according to airflow, pressure, temperature, gas composition, dust concentration, and continuous-duty requirements.

Main Types of Paper Industry Fans
Paper Mill Ventilation Fan
Used for general ventilation, air circulation, moisture removal, and process-area ventilation in paper mills.
Paper Mill Exhaust Fan
Designed to remove humid air, process exhaust, heat, and contaminated air from paper production areas.
Paper Drying Centrifugal Fan
Provides stable airflow and pressure for paper drying and paper machine dryer sections.
Paper Mill Hot Air Circulation Fan
Used for hot air circulation in paper drying and thermal process systems.
Paper Mill Waste Gas Treatment Fan
Used for waste gas collection and transportation in scrubber, absorption, VOC, and environmental treatment systems.
Paper Mill Dust Collection Fan
Designed for collecting and transporting paper dust, fiber particles, and other production dust.
Paper Mill Boiler Fan
Used for boiler forced draft, combustion air supply, induced draft, and flue gas handling.
Paper Mill ID Fan
An induced draft fan designed to maintain furnace negative pressure and transport boiler flue gas.
Paper Mill Material Conveying Fan
Used for pneumatic conveying of lightweight materials, fibers, paper waste, and process residues.
Heavy-Duty Paper Mill Fan
Designed for continuous-duty industrial applications where high load, elevated temperature, dust, or demanding operating conditions are involved.

Main Applications
EMS Paper Industry Fans can be used in:
Pulp and paper production
Paper machine ventilation
Paper drying systems
Dryer section air circulation
Hot air circulation
Paper mill exhaust systems
Waste gas treatment
Dust collection
Fiber conveying
Boiler combustion air supply
Boiler induced draft systems
Flue gas exhaust
Workshop ventilation
Heat recovery systems
Process air supply

Typical Technical Parameters
Parameter Typical Range
Airflow 1,000–300,000 m³/h
Total Pressure 500–15,000 Pa
Static Pressure 300–13,000 Pa
Gas Temperature -20°C to 400°C+
Motor Power 1.1–800 kW
Fan Speed 500–2,900 rpm
Fan Efficiency Up to 85%+
Impeller Diameter 300–3,000 mm
Drive Type Direct / Belt / Coupling
Fan Material Carbon Steel / Stainless Steel / Wear-Resistant Steel
Installation Horizontal / Vertical / Customized
Operation Continuous / Heavy-Duty
The above values are typical engineering reference ranges rather than universal specifications. Final fan selection depends on the actual duty point, gas temperature, gas composition, dust concentration, installation conditions, and operating requirements.
