SDS Tunnel Jet Fan

SDS Tunnel Jet Fan
Product Overview
The SDS Tunnel Jet Fan is an axial-flow jet fan designed for longitudinal ventilation in road tunnels, highway tunnels, underground roads, transportation tunnels, and other large underground facilities.
By generating high-velocity airflow and jet thrust, the fan transfers momentum to the surrounding tunnel air and drives longitudinal airflow through the tunnel. It can be used for normal ventilation, pollutant removal, airflow control, and smoke management during fire emergencies.
EMS provides SDS Tunnel Jet Fans with customized airflow, jet thrust, motor power, reversible operation, high-temperature configuration, mounting systems, and electrical control solutions according to individual tunnel projects.
Main Applications
SDS Tunnel Jet Fans are suitable for:
Road Tunnel Ventilation
Highway Tunnel Ventilation
Urban Road Tunnel Ventilation
Underground Road Ventilation
Railway and Transit Tunnels
Underground Parking Facilities
Long Underground Passages
Tunnel Pollutant Exhaust
Tunnel Smoke Control
Fire Smoke Management
Longitudinal Tunnel Ventilation
Underground Transportation Facilities
Typical Technical Parameters
Parameter Typical Range
Product Type Tunnel Jet Fan
Fan Diameter 500–1600 mm
Airflow 20,000–150,000 m³/h
Jet Velocity 20–40 m/s
Jet Thrust 300–2,500 N
Motor Power 7.5–160 kW
Motor Speed 1,450–2,980 rpm
Operating Temperature -20°C to +60°C
High-Temperature Operation Optional
Airflow Direction Forward / Reversible
Drive Type Direct Drive
Impeller Type Axial Flow
Casing Material Carbon Steel / Stainless Steel
Motor Industrial / Tunnel Ventilation Motor
Installation Ceiling / Side Mounting
Control DOL / Soft Starter / VFD
Duty Continuous Operation
The above values are typical engineering reference ranges rather than fixed specifications for every SDS model. Final fan performance should be selected according to the tunnel ventilation calculation, required jet thrust, smoke-control conditions, and applicable project standards.
