Product Overview
The Industrial Boiler Centrifugal Fan is an industrial centrifugal fan series designed for boiler ventilation systems.
The G4-73 is primarily used as a Forced Draft Fan (FD Fan) for supplying combustion air to the boiler furnace, while the Y4-73 is primarily used as an Induced Draft Fan (ID Fan) for extracting flue gas and maintaining furnace negative pressure.
The series is suitable for industrial steam boilers, hot water boilers, biomass boilers, waste heat boilers, district heating systems and thermal energy facilities.
EMS provides customized configurations according to airflow, pressure, temperature, dust concentration, gas composition, system resistance and installation requirements.
Main Applications
G4-73 Forced Draft Fan
Boiler Combustion Air Supply
Industrial Boiler Forced Draft
Steam Boiler Air Supply
Biomass Boiler Combustion
Heating Boiler Ventilation
Thermal Energy Systems
Y4-73 Induced Draft Fan
Boiler Flue Gas Exhaust
Industrial Boiler Induced Draft
Furnace Negative Pressure Control
Boiler Dust Collection
Flue Gas Treatment
FGD and DeNOx Systems
Industrial Heating Exhaust
Typical Technical Parameters
Parameter Typical Range
Product Type Boiler Centrifugal FD / ID Fan
Airflow 3,000–300,000 m³/h
Total Pressure 1,000–6,000 Pa
Motor Power 5.5–800 kW
Fan Speed 730–2,900 rpm
Air / Gas Temperature Up to 250°C typical
Drive Type Direct / Belt / Coupling
Fan Structure Centrifugal Fan
Impeller Material Carbon Steel / Wear-Resistant Steel
Casing Material Carbon Steel / Customized
Bearing Industrial Heavy-Duty Bearing
Installation Horizontal / Customized
Frequency 50 Hz / 60 Hz
Operation Continuous Duty
Engineering Note: These are typical reference ranges for engineering and website presentation. Actual fan performance should be selected according to the required airflow, pressure, temperature, gas density and total system resistance.
